Input

The Input tab displays various source and frequency values at a glance.

The following table lists all items with a description.

LABEL DESCRIPTION

Input name

Displays the Input Terminal that is presently being used

(see Default input select on page 74).

Signal Displays the Source name of the signal presently being used.

H-sync. freq. Displays Horizontal frequency in KHz.

V-sync. freq. Displays Vertical frequency in Hz.

Video type Displays Video type.

Sync type Displays Sync type.

Sync polarity Displays Sync polarity.

Scan type Displays Scan type.

– 77 –
