Inserting the Remote Control Batteries

Remove the battery compartment

cover by sliding the cover in the di-

rection of the arrow.

Insert the supplied batteries taking

note of the polarity (+/-) as shown

here.

Replace the cover.

Caution:

1. Only use AAA batteries. (Alkaline is better).

2. Dispose of used batteries according to local ordinance regulations.

3. Remove the battery when not using the projector for prolonged periods.
